Holeshot® Series Tires (ATR, XCR, XCT, MXR6, XC, STD, HD, GNCC)

Holeshot® Series

Download Catalog Find a Retailer

Best Used For: All Terrain,Hard Pack,Intermediate Surfaces,Mud,Rocks/Ruts,Sport ATV,Utility ATV

Holeshot Series Tires are Made in the USA.

Holeshot® ATR

Radial tire technology offers amazingly smooth ride quality – flexible sidewalls absorb trail shock
Super strong carcass tracks straight and offers unmatched cornering control
Applications: All-Terrain, Intermediate, Soft/Loose

Holeshot® XCR

Ideal for 4-stroke sport machines
6-ply tough yet light in weight
Lower in profile, narrower and lighter than our XC/XCT models
Special angled shoulder knob design provides increased side bite for faster, more controllable cornering
Applications: All-Terrain, Hard Pack, Intermediate, Rocks/Ruts, Mud

Holeshot® XCT

Our tallest Holeshot tire, making it ideal for rocky desert terrain
Angled knob design provides increased side bite for faster cornering
Applications: All-Terrain, Desert, Intermediate, Rocks/Ruts, Mud

Holeshot® MXR6

Front MXR6 features a longer-wearing tread compound
Rear MXR6 uses a reinforced carcass that minimizes stretching while maintaining a flat profile and providing consistent feel and performance
Applications: Soft/Loose

Holeshot® XC

Offers added handling improvement on any sport quad
Most puncture-resistant sports tire on the market today
Ideal for desert riding and racing
An industry standard, this tire has enjoyed a long, winning history
Applications: All-Terrain, Hard Pack, Intermediate, Rocks/Ruts

Holeshot® STD

One of the most-copied ATV tires – – often imitated, never duplicated!
Patented split-knob design make this one of the best-performing knobbies around
Applications: All-Terrain, Intermediate, Rocks/Ruts

Holeshot® HD

The roughest, toughest Holeshot tire
Wide stance helps to climb out and stay out of ruts
Stepped shoulder knob design offers exceptional side bite and rut control
Stronger sidewall results in improved puncture resistance
Applications: All-Terrain, Hard Pack, Intermediate, Rocks/Ruts, Soft/Loose

Holeshot® GNCC

The ultimate trail riding and GNCC Racing tire
Steers light tracks straight and offer a smooth ride
Exceptional grip, balanced cornering, and unbeatable clean-out
Extended wear compound and puncture-resistant
Applications: All-Terrain, Intermediate, Rocks/Ruts, Soft/Loose

Download Warranty

Technical Specifications

Part Number Sort Order	SKU	Size	Ply	Mounted Diameter (INCH)	Mounted Width (INCH)	Rated Load (POUND)	PSI	Tread Depth	Front or Rear	Weight (POUND)	Additional Information
13	532034	20x11-9	6	20.6000	10.0000	340.0000	7	16 /32	Rear	16.4000
12	532045	22x7-10	4	22.0600	7.2500	255.0000	7	14 /32	Front	13.2000

Part Number Sort Order	SKU	Size	Ply	Mounted Load Diameter (MILLIMETER)	Mounted Width (MILLIMETER)	Rated Load (KILOGRAM)	PSI	Tread Depth	Front or Rear	Weight (KILOGRAM)	Additional Information
13	532034	20x11-9	6	523.2000	254.0000	154.2000	7	12.7	Rear	7.4000
12	532045	22x7-10	4	560.3000	184.2000	115.7000	7	11.1	Front	6.0000

Holeshot® XCR

Standard
Metric

Part Number Sort Order	SKU	Size	Ply	Mounted Diameter (INCH)	Mounted Width (INCH)	Rated Load (POUND)	PSI	Tread Depth	Front or Rear	Weight (POUND)	Additional Information
10	532009	21x7-10	6	21.3200	7.1500	235.0000	7	14 /32	Front	12.5000
11	532054	20X11-9	6	20.1000	10.2000	340.0000	7	17 /32	Rear	14.7000

Part Number Sort Order	SKU	Size	Ply	Mounted Load Diameter (MILLIMETER)	Mounted Width (MILLIMETER)	Rated Load (KILOGRAM)	PSI	Tread Depth	Front or Rear	Weight (KILOGRAM)	Additional Information
10	532009	21x7-10	6	541.5000	181.6000	106.6000	7	11.1	Front	5.7000
11	532054	20X11-9	6	510.5000	259.1000	154.2000	7	13.5	Rear	6.7000

Holeshot® ATR

Standard
Metric

Part Number Sort Order	SKU	Size	Ply	Mounted Diameter (INCH)	Mounted Width (INCH)	Rated Load (POUND)	PSI	Tread Depth	Front or Rear	Weight (POUND)	Additional Information
2	532067	270/60R12	6	25.2500	10.4000	455.0000	7	19 /32	Rear	21.4000
1	532070	205/80R12	6	24.5000	7.6500	340.0000	7	19 /32	Front	14.8000

Part Number Sort Order	SKU	Size	Ply	Mounted Load Diameter (MILLIMETER)	Mounted Width (MILLIMETER)	Rated Load (KILOGRAM)	PSI	Tread Depth	Front or Rear	Weight (KILOGRAM)	Additional Information
2	532067	270/60R12	6	641.4000	264.2000	206.4000	7	15.1	Rear	9.7000
1	532070	205/80R12	6	622.3000	194.3000	154.2000	7	15.1	Front	6.7000

Holeshot® HD

Standard
Metric

Part Number Sort Order	SKU	Size	Ply	Mounted Diameter (INCH)	Mounted Width (INCH)	Rated Load (POUND)	PSI	Tread Depth	Front or Rear	Weight (POUND)	Additional Information
3	532011	22x7-10	6	22.0100	6.4800	255.0000	7	14 /32	Front	12.4000
4	532012	20x11-9	6	20.8000	10.6000	340.0000	7	19 /32	Rear	18.7000

Part Number Sort Order	SKU	Size	Ply	Mounted Load Diameter (MILLIMETER)	Mounted Width (MILLIMETER)	Rated Load (KILOGRAM)	PSI	Tread Depth	Front or Rear	Weight (KILOGRAM)	Additional Information
3	532011	22x7-10	6	559.1000	164.6000	115.7000	7	11.1	Front	5.6000
4	532012	20x11-9	6	528.3000	269.2000	154.2000	7	15.1	Rear	8.5000

Holeshot® XCT

Standard
Metric

Part Number Sort Order	SKU	Size	Ply	Mounted Diameter (INCH)	Mounted Width (INCH)	Rated Load (POUND)	PSI	Tread Depth	Front or Rear	Weight (POUND)	Additional Information
8	532038	22x11-9	6	22.0000	11.7000	395.0000	7	19 /32	Rear	18.7000	SPORT ATV
7	537047	23x7-10	4	22.7500	7.2500	275.0000	10	14 /32	Front	14.0000
9	537051	22x11-10	6	21.9000	10.5700	385.0000	7	19 /32	Rear	19.6000

Part Number Sort Order	SKU	Size	Ply	Mounted Load Diameter (MILLIMETER)	Mounted Width (MILLIMETER)	Rated Load (KILOGRAM)	PSI	Tread Depth	Front or Rear	Weight (KILOGRAM)	Additional Information
8	532038	22x11-9	6	558.8000	297.2000	179.2000	7	15.1	Rear	8.5000	SPORT ATV
7	537047	23x7-10	4	577.9000	184.2000	124.7000	10	11.1	Front	6.4000
9	537051	22x11-10	6	556.3000	268.5000	174.6000	7	15.1	Rear	8.9000

Holeshot® MXR6

Standard
Metric

Part Number Sort Order	SKU	Size	Ply	Mounted Diameter (INCH)	Mounted Width (INCH)	Rated Load (POUND)	PSI	Tread Depth	Front or Rear	Weight (POUND)
18	532021	20x6-10	2	19.8500	6.3000	185.0000	7	11 /32	Front	9.0000
19	532023	18x10-8	2	18.1000	10.0000	260.0000	7	18 /32	Rear	12.3000
20	532024	18x10-9	2	18.0000	9.5000	260.0000	7	19 /32	Rear	10.4000

Part Number Sort Order	SKU	Size	Ply	Mounted Load Diameter (MILLIMETER)	Mounted Width (MILLIMETER)	Rated Load (KILOGRAM)	PSI	Tread Depth	Front or Rear	Weight (KILOGRAM)
18	532021	20x6-10	2	504.2000	160.0000	83.9000	7	8.7	Front	4.1000
19	532023	18x10-8	2	459.7000	254.0000	117.9000	7	14.3	Rear	5.6000
20	532024	18x10-9	2	457.2000	241.3000	117.9000	7	15.1	Rear	4.7000

Holeshot® GNCC

Standard
Metric

Part Number Sort Order	SKU	Size	Ply	Mounted Diameter (INCH)	Mounted Width (INCH)	Rated Load (POUND)	PSI	Tread Depth	Front or Rear	Weight (POUND)	Additional Information
6	532025	20x10-9	6	20.1000	9.6000	300.0000	7	19 /32	Rear	14.2000
5	532029	21x7-10	6	21.5000	6.2000	235.0000	7	19 /32	Front	12.1000

Part Number Sort Order	SKU	Size	Ply	Mounted Load Diameter (MILLIMETER)	Mounted Width (MILLIMETER)	Rated Load (KILOGRAM)	PSI	Tread Depth	Front or Rear	Weight (KILOGRAM)	Additional Information
6	532025	20x10-9	6	510.5000	243.8000	136.1000	7	15.1	Rear	6.4000
5	532029	21x7-10	6	546.1000	157.5000	106.6000	7	15.1	Front	5.5000

Holeshot® STD

Standard
Metric

Part Number Sort Order	SKU	Size	Ply	Mounted Diameter (INCH)	Mounted Width (INCH)	Rated Load (POUND)	PSI	Tread Depth	Front or Rear	Weight (POUND)
14	532031	20x11-8	4	20.8000	11.3000	330.0000	7	16 /32	Rear	14.3000
15	532032	20X11-9	4	20.6000	10.8000	340.0000	7	16 /32	Rear	16.1000
16	532035	20x11-10	4	21.1300	7.1000	330.0000	10	16 /32	Rear	15.1000
17	532040	21x7-10	2	20.4000	8.0300	235.0000	7	14 /32	Front	11.0000

Part Number Sort Order	SKU	Size	Ply	Mounted Load Diameter (MILLIMETER)	Mounted Width (MILLIMETER)	Rated Load (KILOGRAM)	PSI	Tread Depth	Front or Rear	Weight (KILOGRAM)
14	532031	20x11-8	4	528.3000	287.0000	149.7000	7	12.7	Rear	6.5000
15	532032	20X11-9	4	523.2000	274.3000	154.2000	7	12.7	Rear	7.3000
16	532035	20x11-10	4	536.7000	180.3000	149.7000	10	12.7	Rear	6.8000
17	532040	21x7-10	2	518.2000	204.0000	106.6000	7	11.1	Front	5.0000
